#!/usr/bin/env python
"""
.. module:: make_hst_spec_previews
:synopsis: Given an HST spectrum file name, this script will read in the
data and generate preview plots of the spectra. The plots are generated
in different dimensions (large, thumbnail) and, depending on the
instrument / configuration, are plotted in different formats to maximize
readability and usability.
.. moduleauthor:: Scott W. Fleming <fleming@stsci.edu>
"""
#--------------------
# Built-In Imports
#--------------------
from __future__ import absolute_import
from __future__ import print_function
import argparse
from builtins import str
from os import path
import sys
#--------------------
# External Imports
#--------------------
from astropy.io import fits
import numpy
#--------------------
# Package Imports
#--------------------
from spec_plots.utils import specutils, specutils_cos, specutils_stis, specutils_hasp
from spec_plots import __version__
FLUX_SCALE_FACTOR_DEFAULT = 10.
FLUXERR_SCALE_FACTOR_DEFAULT = 5.
N_CONSECUTIVE_DEFAULT = 20
OUTPUT_PATH_DEFAULT = ""
OUTPUT_TYPE_DEFAULT = [str("png")]
DPI_VAL_DEFAULT = 96.
DEBUG_DEFAULT = False
FULL_YLABELS_DEFAULT = False
NOOPTIMIZE_DEFAULT = False
VERBOSE_DEFAULT = False
#--------------------
[docs]
class HSTSpecPrevError(Exception):
"""
This class defines a generic Exception to use for errors raised in
MAKE_HST_SPEC_PREVIEWS. It simply prints the given string when raising the
exception. e.g.,
.. code-block:: python
raise HSTSpecPrevError("Print this string")
HSTSpecPrevError: *** MAKE_HST_SPEC_PREVIEWS ERROR: 'Print this string'
"""
def __init__(self, value):
"""
Initiate the Exception.
:param value: The string to print on error.
:type value: str
"""
super(HSTSpecPrevError, self).__init__(value)
self.value = value
def __str__(self):
"""
Overrides the str function for this class.
"""
return "*** MAKE_HST_SPEC_PREVIEWS ERROR: "+repr(self.value)
#--------------------
#--------------------
[docs]
def get_instrument_name(input_file):
"""
Determines whether the input file is for HASP (Hubbble Advanced
Spectral Product).
:param input_file: Name of input FITS file.
:type input_file: str
:returns: str -- The name of the instrument based on the FITS header
keyword, in uppercase with leading/trailing whitespace removed.
:raises: KeyError, HSTSpecPrevError
"""
# Make sure file exists.
if not path.isfile(input_file):
raise HSTSpecPrevError("Input file not found, looking for file: " +
input_file)
with fits.open(input_file) as hdulist:
# Make sure the INSTRUME keyword exists in the primary header,
# otherwise, catch as a KeyError in this case.
try:
this_instrument = hdulist[0].header["INSTRUME"]
except KeyError:
sys.exit("*** MAKE_HST_SPEC_PREVIEWS ERROR: INSTRUME keyword not"
" found in this file's primary header: " + input_file)
return this_instrument.strip().upper()
#--------------------
[docs]
def is_hasp_product(input_file):
"""
Retrieves the instrument name from a FITS file primary header.
:param input_file: Name of input FITS file.
:type input_file: str
:returns: bool -- Returns True if the filename ends in _aspec.fits or _cspec.fits.
"""
if input_file.endswith("_cspec.fits") or input_file.endswith("_aspec.fits"):
return True
return False
#--------------------
[docs]
def make_hst_spec_previews(input_file, flux_scale_factor=
FLUX_SCALE_FACTOR_DEFAULT, fluxerr_scale_factor=
FLUXERR_SCALE_FACTOR_DEFAULT, n_consecutive=
N_CONSECUTIVE_DEFAULT, output_path=
OUTPUT_PATH_DEFAULT, output_type=OUTPUT_TYPE_DEFAULT,
dpi_val=DPI_VAL_DEFAULT, debug=DEBUG_DEFAULT,
full_ylabels=FULL_YLABELS_DEFAULT, optimize=
not NOOPTIMIZE_DEFAULT, verbose=VERBOSE_DEFAULT):
"""
Main function in the module.
:param input_file: The full path and name of the FITS file to create a
preview for.
:type input_file: str
:param flux_scale_factor: The ratio between the flux and the median flux
that defines the pass/fail criterion within the edge trim test.
:type flux_scale_factor: float
:param fluxerr_scale_factor: The ratio between the flux uncertainty and the
median flux uncertainty that defines the pass/fail criterion within the
edge trim test.
:type fluxerr_scale_factor: float
:param n_consecutive: The number of consecutive data points that must pass
the edge trim test to define the start and end of the spectrum for
plotting purposes.
:type n_consecutive: int
:param output_path: Full path to output plot files. Do not include the
output file name in this path. If not supplied, plots will be created
in the same directory as the input file.
:type output_path: str
:param output_type: The file type(s) of the plots to make.
:type output_type: list
:param dpi_val: The DPI value of your device's monitor, which will affect
the size of the output plots.
:type dpi_val: float
:param debug: If True, turns on debug mode, which will plot to the screen
and color-code fluxes based on different rejection criteria.
:type debug: bool
:param full_ylabels: If True, label the y-axis with full values, including
powers of ten in scientific notation.
:type full_ylabels: bool
:param optimize: If set to True, will use a slightly optimized version of
determining the plot covering fraction.
:type optimize: bool
:param verbose: Turn on verbose messages/logging?
:type verbose: bool
:raises: HSTSpecPrevError
"""
# Print file name, if verbose is turned on.
if verbose:
print("Input file: " + input_file)
# Derive output file names from input file name.
output_files = []
for out_type in output_type:
if out_type != "screen":
if out_type != "fits":
output_file = (path.join(output_path, "") +
path.basename(input_file).split(".fits")[0] +
"." + out_type)
else:
output_file = (path.join(output_path, "") +
path.basename(input_file).split(".fits")[0] +
"_prev." + out_type)
else:
output_file = None
output_files.append(output_file)
# Print name of output file.
if verbose:
print("Output file names are:")
for ofile in output_files:
if ofile is not None:
if ofile[-4:] == '.png':
print(" Output file: " + ofile)
print(" Output file: " + ofile.split('.png')[0] +
'_thumb.png')
else:
print(" Output file: " + ofile)
else:
print(" Plotting to screen.")
# Handle previews for HASP products.
if is_hasp_product(input_file):
if verbose:
print("HASP product")
# Get wavelengths, fluxes, flux uncertainties.
hasp_spectrum = specutils_hasp.readspec(input_file)
# Make "large-size" plot.
for out_type, out_file in zip(output_type, output_files):
if out_type != 'fits':
# Make "large-size" plot
hasp_plot_metrics = specutils.calc_plot_metrics("hasp",
hasp_spectrum.wavelengths,
hasp_spectrum.fluxes,
hasp_spectrum.fluxerrs,
hasp_spectrum.dqs,
1, flux_scale_factor, fluxerr_scale_factor)
specutils_hasp.plotspec(hasp_spectrum,
out_type, out_file,
flux_scale_factor, fluxerr_scale_factor,
hasp_plot_metrics,
dpi_val=dpi_val, output_size=1024,
debug=debug, full_ylabels=full_ylabels,
optimize=optimize)
# Make "thumbnail-size" plot, if requested. Notice that in this
# case we always plot just the first association, by passing only
# `stitched_spectra[0]`.
if not debug:
specutils_hasp.plotspec(hasp_spectrum,
out_type, out_file,
flux_scale_factor, fluxerr_scale_factor,
hasp_plot_metrics,
dpi_val=dpi_val,
output_size=128, optimize=optimize)
return
# Read in the FITS file to determine which instrument it comes from.
# Print the name of the instrument found in the header if verbose is turned
# on.
this_instrument = get_instrument_name(input_file)
if verbose:
print("Instrument: " + this_instrument)
# Read in the FITS files and create plots using the local package
# appropriate for the instrument used in the input file.
if this_instrument == "COS":
# Get wavelengths, fluxes, flux uncertainties.
cos_spectrum = specutils_cos.readspec(input_file)
# Get a list of segment names sorted such that the bluest segment is
# first.
cos_segment_names = specutils_cos.get_segment_names(cos_spectrum)
# Trim the wavelengths < 900 Angstroms for FUVB segment if optical
# element used is G140L.
if ("FUVB" in cos_spectrum.segments and cos_spectrum.optical_element ==
"G140L"):
specutils_cos.extract_subspec(cos_spectrum, "FUVB", min_wl=900.)
# Create a stitched spectrum for use when making thumb-size plots.
stitched_spectrum = specutils.stitch_components(cos_spectrum,
n_consecutive,
flux_scale_factor,
fluxerr_scale_factor,
segment_names=
cos_segment_names)
# Calculate plot metrics for the each segment.
segment_plot_metrics = [
specutils.calc_plot_metrics("cos",
cos_spectrum.segments[x].wavelengths,
cos_spectrum.segments[x].fluxes,
cos_spectrum.segments[x].fluxerrs,
cos_spectrum.segments[x].dqs,
n_consecutive, flux_scale_factor,
fluxerr_scale_factor)
for x in cos_segment_names]
# Make "large-size" plot.
for out_type, out_file in zip(output_type, output_files):
if out_type != "fits":
specutils_cos.plotspec(cos_spectrum, out_type, out_file,
flux_scale_factor,
fluxerr_scale_factor,
segment_plot_metrics,
dpi_val=dpi_val, output_size=1024,
debug=debug, full_ylabels=full_ylabels,
title_addendum=stitched_spectrum["title"],
optimize=optimize)
else:
# Write the spectrum that would be plotted to a binary FITS
# table.
specutils_cos.make_fits(cos_spectrum, out_file,
segment_plot_metrics, input_file)
if not debug and output_type != ["fits"]:
# Calculate plot metrics for the stitched spectrum.
stitched_plot_metrics = [
specutils.calc_plot_metrics("cos", stitched_spectrum["wls"],
stitched_spectrum["fls"],
stitched_spectrum["flerrs"],
stitched_spectrum["dqs"],
n_consecutive, flux_scale_factor,
fluxerr_scale_factor)]
# Make "thumbnail-size" plot, if requested.
for out_type, out_file in zip(output_type, output_files):
if out_type != 'fits':
specutils_cos.plotspec(cos_spectrum, out_type,
out_file, flux_scale_factor,
fluxerr_scale_factor,
stitched_plot_metrics,
dpi_val=dpi_val, output_size=128,
stitched_spectrum=stitched_spectrum,
optimize=optimize)
elif this_instrument == "STIS":
# Get wavelengths, fluxes, flux uncertainties.
stis_spectrum = specutils_stis.readspec(input_file)
# Get the indices to plot. If the number of associations is <=3 then
# we will plot all of them, but if >3 then only the first, middle, and
# last association will be plotted, so it's not necessary to stitch or
# calculate plot metrics for any of the others.
indices_to_plot = specutils_stis.get_association_indices(
stis_spectrum.associations)
# Create a stitched spectrum for each association, used when making
# thumb-size plots. The stitched spectrum joins the orders together (if
# there is more than one). The length of the returned list is equal to
# the number of associations that will be plotted.
stitched_spectra = [
specutils.stitch_components(x, n_consecutive, flux_scale_factor,
fluxerr_scale_factor)
for x in numpy.asarray(stis_spectrum.associations)[indices_to_plot]]
# Calculate plot metrics for the each association that will be
# plotted. The length of the returned list is equal to the number of
# associations that will be plotted.
association_plot_metrics = [
specutils.calc_plot_metrics("stis", x["wls"], x["fls"], x["flerrs"],
x["dqs"], n_consecutive,
flux_scale_factor, fluxerr_scale_factor)
for x in stitched_spectra]
# Make "large-size" plot.
for out_type, out_file in zip(output_type, output_files):
if out_type != 'fits':
specutils_stis.plotspec(stis_spectrum, indices_to_plot,
stitched_spectra, out_type, out_file,
flux_scale_factor, fluxerr_scale_factor,
association_plot_metrics,
dpi_val=dpi_val, output_size=1024,
debug=debug, full_ylabels=full_ylabels,
optimize=optimize)
# Make "thumbnail-size" plot, if requested. Notice that in this
# case we always plot just the first association, by passing only
# `stitched_spectra[0]`.
if not debug:
specutils_stis.plotspec(stis_spectrum, indices_to_plot,
[stitched_spectra[0]], out_type,
out_file, flux_scale_factor,
fluxerr_scale_factor,
association_plot_metrics,
dpi_val=dpi_val,
output_size=128, optimize=optimize)
else:
raise HSTSpecPrevError("'INSTRUME' keyword not understood: " +
this_instrument)
#--------------------
[docs]
def setup_args():
"""
Set up command-line arguments and options.
:returns: ArgumentParser -- Stores arguments and options.
"""
parser = argparse.ArgumentParser(
description="Create spectroscopic preview plots given an HST spectrum"
" FITS file.")
parser.add_argument("input_file", action="store", type=str, help=
"[Required] Full path to input file (HST spectrum) for"
" which to generate preview plots. Include the file"
" name in the path.")
parser.add_argument("-d", action="store_true", dest="debug", default=
DEBUG_DEFAULT, help="[Optional] Turn on debug mode,"
" which will plot to the screen and color-code fluxes"
" based on different rejection criteria. Default ="
" %(default)s.")
parser.add_argument("--dpival", action="store", type=float, dest="dpi_val",
default=DPI_VAL_DEFAULT, help="[Optional] Specify the"
" DPI value of your device's monitor, which will affect"
" the size of the output plots. Default ="
" %(default)s.")
parser.add_argument("-e", action="store", type=float, dest=
"fluxerr_scale_factor", default=
FLUXERR_SCALE_FACTOR_DEFAULT, help="[Optional] Specify"
" the ratio between the flux uncertainty and the median"
" flux uncertainty that defines the pass/fail criterion"
" within the edge trim test. Default = %(default)s.")
parser.add_argument("-n", action="store", type=int, dest="n_consecutive",
default=N_CONSECUTIVE_DEFAULT, help="[Optional] Specify"
" the number of consecutive data points that must pass"
" the edge trim test to define the start and end of the"
" spectrum for plotting purposes. Default ="
" %(default)i.")
parser.add_argument("--nooptimize", action="store_true", dest="nooptimize",
default=NOOPTIMIZE_DEFAULT, help="[Optional] If True,"
" do not use an optimized method of calculating plot"
" covering fraction to determine line transparency."
" Default = %(default)s.")
parser.add_argument("-o", action="store", type=str, dest="output_path",
default=OUTPUT_PATH_DEFAULT, help="[Optional] Full path"
" to output plot files. Do not include file name in"
" path. Default is to output to the same directory"
" as the input file.")
parser.add_argument("-s", action="store", type=float, dest=
"flux_scale_factor", default=FLUX_SCALE_FACTOR_DEFAULT,
help="[Optional] Specify the ratio between the flux and"
" the median flux that defines the pass/fail criterion"
" within the edge trim test. Default = %(default)s.")
parser.add_argument("-t", nargs='+', action="store", type=str, dest=
"output_type", default=OUTPUT_TYPE_DEFAULT, help=
"[Optional] Specify the file type of the plots to make."
" Default = %(default)s.", choices=['png', 'eps',
'screen', 'fits'],
metavar="{png,ps,screen,fits}")
parser.add_argument("-v", action="store_true", dest="verbose",
default=VERBOSE_DEFAULT, help="[Optional] Turn on"
" verbose messages/logging? Default = %(default)s.")
parser.add_argument("-y", action="store_true", dest="full_ylabels",
default=FULL_YLABELS_DEFAULT, help="[Optional] Label"
" the y-axis with full values, including powers of ten"
" in scientific notation? Default = %(default)s.")
return parser
#--------------------
if __name__ == "__main__":
# Create ArgumentParser object that holds arguments and options.
INPUT_ARGS = setup_args().parse_args()
# Check arguments and options.
check_input_options(INPUT_ARGS)
# Call main function.
make_hst_spec_previews(INPUT_ARGS.input_file,
flux_scale_factor=INPUT_ARGS.flux_scale_factor,
fluxerr_scale_factor=INPUT_ARGS.fluxerr_scale_factor,
n_consecutive=INPUT_ARGS.n_consecutive,
output_path=INPUT_ARGS.output_path,
output_type=INPUT_ARGS.output_type,
dpi_val=INPUT_ARGS.dpi_val,
debug=INPUT_ARGS.debug,
full_ylabels=INPUT_ARGS.full_ylabels,
optimize=not INPUT_ARGS.nooptimize,
verbose=INPUT_ARGS.verbose)
#--------------------
